Vol. 1 9-1

CHAPTER 9

PROGRAMMING WITH INTEL® MMX™ TECHNOLOGY

The Intel MMX technology was introduced into the IA-32 architecture in the Pentium II processor family and
Pentium processor with MMX technology. The extensions introduced in MMX technology support a single-instruc-

tion, multiple-data (SIMD) execution model that is designed to accelerate the performance of advanced media and
communications applications.
This chapter describes MMX technology.

9.1

OVERVIEW OF MMX TECHNOLOGY

MMX technology defines a simple and flexible SIMD execution model to handle 64-bit packed integer data. This
model adds the following features to the IA-32 architecture, while maintaining backwards compatibility with all IA-
32 applications and operating-system code:

•

Eight new 64-bit data registers, called MMX registers

•

Three new packed data types:
— 64-bit packed byte integers (signed and unsigned)
— 64-bit packed word integers (signed and unsigned)
— 64-bit packed doubleword integers (signed and unsigned)

•

Instructions that support the new data types and to handle MMX state management

•

Extensions to the CPUID instruction

MMX technology is accessible from all the IA32-architecture execution modes (protected mode, real address mode,
and virtual 8086 mode). It does not add any new modes to the architecture.
The following sections of this chapter describe MMX technology’s programming environment, including MMX
register set, data types, and instruction set. Additional instructions that operate on MMX registers have been added
to the IA-32 architecture by the SSE/SSE2 extensions.
For more information, see:

•

Section 10.4.4, “SSE 64-Bit SIMD Integer Instructions,” describes MMX instructions added to the IA-32 archi-
tecture with the SSE extensions.

•

Section 11.4.2, “SSE2 64-Bit and 128-Bit SIMD Integer Instructions,” describes MMX instructions added to the
IA-32 architecture with SSE2 extensions.

•

Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volumes 2A & 2B, give detailed descriptions
of MMX instructions.

•

Chapter 12, “Intel® MMX™ Technology System Programming,” in the Intel® 64 and IA-32 Architectures
Software Developer’s Manual, Volume 3B, describes the manner in which MMX technology is integrated into the
IA-32 system programming model.

9.2

THE MMX TECHNOLOGY PROGRAMMING ENVIRONMENT

Figure 9-1 shows the execution environment for MMX technology. All MMX instructions operate on MMX registers,
the general-purpose registers, and/or memory as follows:

•

MMX registers — These eight registers (see Figure 9-1) are used to perform operations on 64-bit packed
integer data. They are named MM0 through MM7.
