CPUID—CPU Identification
INSTRUCTION SET REFERENCE, A-L
3-204 Vol. 2A
NOTE
See Chapter 19 in the Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 1,
for information on identifying earlier IA-32 processors.
The Extended Family ID needs to be examined only when the Family ID is 0FH. Integrate the fields into a display
using the following rule:
IF Family_ID
â‰
0FH
THEN DisplayFamily = Family_ID;
ELSE DisplayFamily = Extended_Family_ID + Family_ID;
(* Right justify and zero-extend 4-bit field. *)
FI;
(* Show DisplayFamily as HEX field. *)
The Extended Model ID needs to be examined only when the Family ID is 06H or 0FH. Integrate the field into a
display using the following rule:
IF (Family_ID = 06H or Family_ID = 0FH)
THEN DisplayModel = (Extended_Model_ID « 4) + Model_ID;
(* Right justify and zero-extend 4-bit field; display Model_ID as HEX field.*)
ELSE DisplayModel = Model_ID;
FI;
(* Show DisplayModel as HEX field. *)
INPUT EAX = 01H: Returns Additional Information in EBX
When CPUID executes with EAX set to 01H, additional information is returned to the EBX register:
•
Brand index (low byte of EBX) — this number provides an entry into a brand string table that contains brand
strings for IA-32 processors. More information about this field is provided later in this section.
•
CLFLUSH instruction cache line size (second byte of EBX) — this number indicates the size of the cache line
flushed by the CLFLUSH and CLFLUSHOPT instructions in 8-byte increments. This field was introduced in the
Pentium 4 processor.
•
Local APIC ID (high byte of EBX) — this number is the 8-bit ID that is assigned to the local APIC on the
processor during power up. This field was introduced in the Pentium 4 processor.
INPUT EAX = 01H: Returns Feature Information in ECX and EDX
When CPUID executes with EAX set to 01H, feature information is returned in ECX and EDX.
•
Figure 3-7 and Table 3-10 show encodings for ECX.
•
Figure 3-8 and Table 3-11 show encodings for EDX.
For all feature flags, a 1 indicates that the feature is supported. Use Intel to properly interpret feature flags.
NOTE
Software must confirm that a processor feature is present using feature flags returned by CPUID
prior to using the feature. Software should not depend on future offerings retaining all features.
Table 3-9. Processor Type Field
Type
Encoding
Original OEM Processor
00B
Intel OverDrive
®
Processor
01B
Dual processor (not applicable to Intel486 processors)
10B
Intel reserved
11B
