7-16 Vol. 1

PROGRAMMING WITH GENERAL-PURPOSE INSTRUCTIONS

The destination operand specifies a relative address (a signed offset with respect to the address in the EIP register)
that points to an instruction in the current code segment. The Jcc instructions do not support far transfers;
however, far transfers can be accomplished with a combination of a Jcc and a JMP instruction (see “Jcc—Jump if
Condition Is Met” in Chapter 3, “Instruction Set Reference, A-L,” of the Intel® 64 and IA-32 Architectures Software
Developer’s Manual, Volume 2A).
Table 7-4 shows the mnemonics for the Jcc instructions and the conditions being tested for each instruction. The
condition code mnemonics are appended to the letter “J” to form the mnemonic for a Jcc instruction. The instruc-
tions are divided into two groups: unsigned and signed conditional jumps. These groups correspond to the results
of operations performed on unsigned and signed integers respectively. Those instructions listed as pairs (for
example, JA/JNBE) are alternate names for the same instruction. Assemblers provide alternate names to make it
easier to read program listings.
The JCXZ and JECXZ instructions test the CX and ECX registers, respectively, instead of one or more status flags.
See “Jump if zero instructions” on page 7-17 for more information about these instructions.
Loop instructions — The LOOP, LOOPE (loop while equal), LOOPZ (loop while zero), LOOPNE (loop while not
equal), and LOOPNZ (loop while not zero) instructions are conditional jump instructions that use the value of the
ECX register as a count for the number of times to execute a loop. All the loop instructions decrement the count in
the ECX register each time they are executed and terminate a loop when zero is reached. The LOOPE, LOOPZ,
LOOPNE, and LOOPNZ instructions also accept the ZF flag as a condition for terminating the loop before the count
reaches zero.
The LOOP instruction decrements the contents of the ECX register (or the CX register, if the address-size attribute
is 16), then tests the register for the loop-termination condition. If the count in the ECX register is non-zero,
program control is transferred to the instruction address specified by the destination operand. The destination

Table 7-4.  Conditional Jump Instructions

Instruction Mnemonic

Condition (Flag States)

Description

Unsigned Conditional Jumps
  JA/JNBE

(CF or ZF) = 0

Above/not below or equal

  JAE/JNB

CF = 0

Above or equal/not below

  JB/JNAE

CF = 1

Below/not above or equal

  JBE/JNA

(CF or ZF) = 1

Below or equal/not above

  JC

CF = 1

Carry

  JE/JZ

ZF = 1

Equal/zero

  JNC

CF = 0

Not carry

  JNE/JNZ

ZF = 0

Not equal/not zero

  JNP/JPO

PF = 0

Not parity/parity odd

  JP/JPE

PF = 1

Parity/parity even

  JCXZ

CX = 0

Register CX is zero

  JECXZ

ECX = 0

Register ECX is zero

Signed Conditional Jumps
  JG/JNLE

((SF xor OF) or ZF) = 0

Greater/not less or equal

  JGE/JNL

(SF xor OF) = 0

Greater or equal/not less

  JL/JNGE

(SF xor OF) = 1

Less/not greater or equal

  JLE/JNG

((SF xor OF) or ZF) = 1

Less or equal/not greater

  JNO

OF = 0

Not overflow

  JNS

SF = 0

Not sign (non-negative)

  JO

OF = 1

Overflow

  JS

SF = 1

Sign (negative)
