NOP—No Operation
INSTRUCTION SET REFERENCE, M-U
Vol. 2B 4-163
NOP—No Operation
Instruction Operand Encoding
Description
This instruction performs no operation. It is a one-byte or multi-byte NOP that takes up space in the instruction
stream but does not impact machine context, except for the EIP register.
The multi-byte form of NOP is available on processors with model encoding:
•
CPUID.01H.EAX[Bytes 11:8] = 0110B or 1111B
The multi-byte NOP instruction does not alter the content of a register and will not issue a memory operation. The
instruction’s operation is the same in non-64-bit modes and 64-bit mode.
Operation
The one-byte NOP instruction is an alias mnemonic for the XCHG (E)AX, (E)AX instruction.
The multi-byte NOP instruction performs no operation on supported processors and generates undefined opcode
exception on processors that do not support the multi-byte NOP instruction.
The memory operand form of the instruction allows software to create a byte sequence of “no operation” as one
instruction. For situations where multiple-byte NOPs are needed, the recommended operations (32-bit mode and
64-bit mode) are:
Flags Affected
None
Exceptions (All Operating Modes)
#UD
If the LOCK prefix is used.
Opcode
Instruction
Op/
En
64-Bit
Mode
Compat/
Leg Mode
Description
90
NOP
NP
Valid
Valid
One byte no-operation instruction.
0F 1F /0
NOP r/m16
M
Valid
Valid
Multi-byte no-operation instruction.
0F 1F /0
NOP r/m32
M
Valid
Valid
Multi-byte no-operation instruction.
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
NP
NA
NA
NA
NA
M
ModRM:r/m (r)
NA
NA
NA
Table 4-12. Recommended Multi-Byte Sequence of NOP Instruction
Length
Assembly
Byte Sequence
2 bytes
66 NOP
66 90H
3 bytes
NOP DWORD ptr [EAX]
0F 1F 00H
4 bytes
NOP DWORD ptr [EAX + 00H]
0F 1F 40 00H
5 bytes
NOP DWORD ptr [EAX + EAX*1 + 00H]
0F 1F 44 00 00H
6 bytes
66 NOP DWORD ptr [EAX + EAX*1 + 00H]
66 0F 1F 44 00 00H
7 bytes
NOP DWORD ptr [EAX + 00000000H]
0F 1F 80 00 00 00 00H
8 bytes
NOP DWORD ptr [EAX + EAX*1 + 00000000H]
0F 1F 84 00 00 00 00 00H
9 bytes
66 NOP DWORD ptr [EAX + EAX*1 + 00000000H]
66 0F 1F 84 00 00 00 00 00H
