MOV—Move to/from Control Registers

INSTRUCTION SET REFERENCE, M-U

4-40 Vol. 2B

MOV—Move to/from Control Registers

Instruction Operand Encoding

Description

Moves the contents of a control register (CR0, CR2, CR3, CR4, or CR8) to a general-purpose register or the
contents of a general purpose register to a control register. The operand size for these instructions is always 32 bits
in non-64-bit modes, regardless of the operand-size attribute. (See “Control Registers” in Chapter 2 of the Intel®
64 and IA-32 Architectures Software Developer’s Manual, Volume 3A, for a detailed description of the flags and
fields in the control registers.) This instruction can be executed only when the current privilege level is 0.
At the opcode level, the reg field within the ModR/M byte specifies which of the control registers is loaded or read.
The 2 bits in the mod field are ignored. The r/m field specifies the general-purpose register loaded or read.
Attempts to reference CR1, CR5, CR6, CR7, and CR9–CR15 result in undefined opcode (#UD) exceptions.
When loading control registers, programs should not attempt to change the reserved bits; that is, always set
reserved bits to the value previously read. An attempt to change CR4's reserved bits will cause a general protection
fault. Reserved bits in CR0 and CR3 remain clear after any load of those registers; attempts to set them have no
impact. On Pentium 4, Intel Xeon and P6 family processors, CR0.ET remains set after any load of CR0; attempts to
clear this bit have no impact.
In certain cases, these instructions have the side effect of invalidating entries in the TLBs and the paging-structure
caches. See Section 4.10.4.1, “Operations that Invalidate TLBs and Paging-Structure Caches,” in the Intel® 64 and
IA-32 Architectures Software Developer’s Manual, Volume 3A for details.
The following side effects are implementation-specific for the Pentium 4, Intel Xeon, and P6 processor family: when
modifying PE or PG in register CR0, or PSE or PAE in register CR4, all TLB entries are flushed, including global
entries. Software should not depend on this functionality in all Intel 64 or IA-32 processors.
In 64-bit mode, the instruction’s default operation size is 64 bits. The REX.R prefix must be used to access CR8. Use
of REX.B permits access to additional registers (R8-R15). Use of the REX.W prefix or 66H prefix is ignored. Use of

Opcode/

Instruction

Op/

En

64-Bit

Mode

Compat/

Leg Mode

Description

0F 20/r
MOV r32, CR0–CR7

MR

N.E.

Valid

Move control register to r32.

0F 20/r
MOV r64, CR0–CR7

MR

Valid

N.E.

Move extended control register to r64.

REX.R + 0F 20 /0
MOV r64, CR8

MR

Valid

N.E.

Move extended CR8 to r64.

1

0F 22 /r
MOV CR0–CR7, r32

RM

N.E.

Valid

Move r32 to control register.

0F 22 /r
MOV CR0–CR7, r64

RM

Valid N.E.

Move

r64 to extended control register.

REX.R + 0F 22 /0
MOV CR8, r64

RM

Valid

N.E.

Move r64 to extended CR8.

1

NOTE:

1.  MOV CR* instructions, except for MOV CR8, are serializing instructions. MOV CR8 is not

architecturally defined as a serializing instruction. For more information, see Chapter 8 in Intel® 64 and IA-32 Architectures Soft-

ware Developer’s Manual, Volume 3A.

Op/En

Operand 1

Operand 2

Operand 3

Operand 4

MR

ModRM:r/m (w)

ModRM:reg (r)

NA

NA

RM

ModRM:reg (w)

ModRM:r/m (r)

NA

NA
