FLD1/FLDL2T/FLDL2E/FLDPI/FLDLG2/FLDLN2/FLDZ—Load Constant
INSTRUCTION SET REFERENCE, A-L
3-354 Vol. 2A
FLD1/FLDL2T/FLDL2E/FLDPI/FLDLG2/FLDLN2/FLDZ—Load Constant
Description
Push one of seven commonly used constants (in double extended-precision floating-point format) onto the FPU
register stack. The constants that can be loaded with these instructions include +1.0, +0.0, log
2
10, log
2
e, π, log
10
2,
and log
e
2. For each constant, an internal 66-bit constant is rounded (as specified by the RC field in the FPU control
word) to double extended-precision floating-point format. The inexact-result exception (#P) is not generated as a
result of the rounding, nor is the C1 flag set in the x87 FPU status word if the value is rounded up.
See the section titled “Approximation of Pi” in Chapter 8 of the Intel® 64 and IA-32 Architectures Software Devel-
oper’s Manual, Volume 1, for a description of the π constant.
This instruction’s operation is the same in non-64-bit modes and 64-bit mode.
IA-32 Architecture Compatibility
When the RC field is set to round-to-nearest, the FPU produces the same constants that is produced by the Intel
8087 and Intel 287 math coprocessors.
Operation
TOP ← TOP
−
1;
ST(0) ← CONSTANT;
FPU Flags Affected
C1
Set to 1 if stack overflow occurred; otherwise, set to 0.
C0, C2, C3
Undefined.
Floating-Point Exceptions
#IS
Stack overflow occurred.
Protected Mode Exceptions
#NM
CR0.EM[bit 2] or CR0.TS[bit 3] = 1.
#MF
If there is a pending x87 FPU exception.
#UD
If the LOCK prefix is used.
Real-Address Mode Exceptions
Same exceptions as in protected mode.
Virtual-8086 Mode Exceptions
Same exceptions as in protected mode.
Opcode*
Instruction
64-Bit
Mode
Compat/
Leg Mode
Description
D9 E8
FLD1
Valid
Valid
Push +1.0 onto the FPU register stack.
D9 E9
FLDL2T
Valid
Valid
Push log
2
10 onto the FPU register stack.
D9 EA
FLDL2E
Valid
Valid
Push log
2
e onto the FPU register stack.
D9 EB
FLDPI
Valid
Valid
Push π onto the FPU register stack.
D9 EC
FLDLG2
Valid
Valid
Push log
10
2 onto the FPU register stack.
D9 ED
FLDLN2
Valid
Valid
Push log
e
2 onto the FPU register stack.
D9 EE
FLDZ
Valid
Valid
Push +0.0 onto the FPU register stack.
NOTES:
* See IA-32 Architecture Compatibility section below.
