CVTTPS2PI—Convert with Truncation Packed Single-Precision FP Values to Packed Dword Integers

INSTRUCTION SET REFERENCE, A-L

3-272 Vol. 2A

CVTTPS2PI—Convert with Truncation Packed Single-Precision FP Values to Packed Dword

Integers

Instruction Operand Encoding

Description

Converts two packed single-precision floating-point values in the source operand (second operand) to two packed
signed doubleword integers in the destination operand (first operand). The source operand can be an XMM register
or a 64-bit memory location. The destination operand is an MMX technology register. When the source operand is
an XMM register, the two single-precision floating-point values are contained in the low quadword of the register.
When a conversion is inexact, a truncated (round toward zero) result is returned. If a converted result is larger than
the maximum signed doubleword integer, the floating-point invalid exception is raised, and if this exception is
masked, the indefinite integer value (80000000H) is returned.
This instruction causes a transition from x87 FPU to MMX technology operation (that is, the x87 FPU top-of-stack
pointer is set to 0 and the x87 FPU tag word is set to all 0s [valid]). If this instruction is executed while an x87 FPU
floating-point exception is pending, the exception is handled before the CVTTPS2PI instruction is executed.
In 64-bit mode, use of the REX.R prefix permits this instruction to access additional registers (XMM8-XMM15).

Operation

DEST[31:0] ← Convert_Single_Precision_Floating_Point_To_Integer_Truncate(SRC[31:0]);

DEST[63:32] ← Convert_Single_Precision_Floating_Point_To_Integer_Truncate(SRC[63:32]);

Intel C/C++ Compiler Intrinsic Equivalent

CVTTPS2PI:

__m64 _mm_cvttps_pi32(__m128 a)

SIMD Floating-Point Exceptions

Invalid, Precision

Other Exceptions

See Table 22-5, “Exception Conditions for Legacy SIMD/MMX Instructions with XMM and FP Exception,” in the
Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 3B.

Opcode/

Instruction

Op/

En

64-Bit

Mode

Compat/

Leg Mode

Description

0F 2C /r
CVTTPS2PI mm, xmm/m64

RM

Valid

Valid

Convert two single-precision floating-point

values from xmm/m64 to two signed

doubleword signed integers in mm using

truncation.

Op/En

Operand 1

Operand 2

Operand 3

Operand 4

RM

ModRM:reg (w)

ModRM:r/m (r)

NA

NA
