CVTTPD2PI—Convert with Truncation Packed Double-Precision FP Values to Packed Dword Integers
INSTRUCTION SET REFERENCE, A-L
3-268 Vol. 2A
CVTTPD2PI—Convert with Truncation Packed Double-Precision FP Values to Packed Dword
Integers
Instruction Operand Encoding
Description
Converts two packed double-precision floating-point values in the source operand (second operand) to two packed
signed doubleword integers in the destination operand (first operand). The source operand can be an XMM register
or a 128-bit memory location. The destination operand is an MMX technology register.
When a conversion is inexact, a truncated (round toward zero) result is returned. If a converted result is larger than
the maximum signed doubleword integer, the floating-point invalid exception is raised, and if this exception is
masked, the indefinite integer value (80000000H) is returned.
This instruction causes a transition from x87 FPU to MMX technology operation (that is, the x87 FPU top-of-stack
pointer is set to 0 and the x87 FPU tag word is set to all 0s [valid]). If this instruction is executed while an x87 FPU
floating-point exception is pending, the exception is handled before the CVTTPD2PI instruction is executed.
In 64-bit mode, use of the REX.R prefix permits this instruction to access additional registers (XMM8-XMM15).
Operation
DEST[31:0] ← Convert_Double_Precision_Floating_Point_To_Integer32_Truncate(SRC[63:0]);
DEST[63:32] ← Convert_Double_Precision_Floating_Point_To_Integer32_
Truncate(SRC[127:64]);
Intel C/C++ Compiler Intrinsic Equivalent
CVTTPD1PI:
__m64 _mm_cvttpd_pi32(__m128d a)
SIMD Floating-Point Exceptions
Invalid, Precision
Other Mode Exceptions
Opcode/
Instruction
Op/
En
64-Bit
Mode
Compat/
Leg Mode
Description
66 0F 2C /r
CVTTPD2PI mm, xmm/m128
RM
Valid
Valid
Convert two packer double-precision floating-
point values from xmm/m128 to two packed
signed doubleword integers in mm using
truncation.
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM
ModRM:reg (w)
ModRM:r/m (r)
NA
NA
