CVTPS2PI—Convert Packed Single-Precision FP Values to Packed Dword Integers

INSTRUCTION SET REFERENCE, A-L

Vol. 2A 3-251

CVTPS2PI—Convert Packed Single-Precision FP Values to Packed Dword Integers

Instruction Operand Encoding

Description

Converts two packed single-precision floating-point values in the source operand (second operand) to two packed
signed doubleword integers in the destination operand (first operand).
The source operand can be an XMM register or a 128-bit memory location. The destination operand is an MMX tech-
nology register. When the source operand is an XMM register, the two single-precision floating-point values are
contained in the low quadword of the register. When a conversion is inexact, the value returned is rounded
according to the rounding control bits in the MXCSR register. If a converted result is larger than the maximum
signed doubleword integer, the floating-point invalid exception is raised, and if this exception is masked, the indef-
inite integer value (80000000H) is returned.
CVTPS2PI causes a transition from x87 FPU to MMX technology operation (that is, the x87 FPU top-of-stack pointer
is set to 0 and the x87 FPU tag word is set to all 0s [valid]). If this instruction is executed while an x87 FPU floating-
point exception is pending, the exception is handled before the CVTPS2PI instruction is executed.
In 64-bit mode, use of the REX.R prefix permits this instruction to access additional registers (XMM8-XMM15).

Operation

DEST[31:0] ← Convert_Single_Precision_Floating_Point_To_Integer(SRC[31:0]);

DEST[63:32] ← Convert_Single_Precision_Floating_Point_To_Integer(SRC[63:32]);

Intel C/C++ Compiler Intrinsic Equivalent

CVTPS2PI:

__m64 _mm_cvtps_pi32(__m128 a)

SIMD Floating-Point Exceptions

Invalid, Precision

Other Exceptions

See Table 22-5, “Exception Conditions for Legacy SIMD/MMX Instructions with XMM and FP Exception,” in the
Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 3B.

Opcode/

Instruction

Op/

En

64-Bit

Mode

Compat/

Leg Mode

Description

0F 2D /r
CVTPS2PI mm, xmm/m64

RM

Valid

Valid

Convert two packed single-precision floating-

point values from xmm/m64 to two packed

signed doubleword integers in mm.

Op/En

Operand 1

Operand 2

Operand 3

Operand 4

RM

ModRM:reg (w)

ModRM:r/m (r)

NA

NA
