CVTPI2PS—Convert Packed Dword Integers to Packed Single-Precision FP Values

INSTRUCTION SET REFERENCE, A-L

3-244 Vol. 2A

CVTPI2PS—Convert Packed Dword Integers to Packed Single-Precision FP Values

Instruction Operand Encoding

Description

Converts two packed signed doubleword integers in the source operand (second operand) to two packed single-
precision floating-point values in the destination operand (first operand).
The source operand can be an MMX technology register or a 64-bit memory location. The destination operand is an
XMM register. The results are stored in the low quadword of the destination operand, and the high quadword
remains unchanged. When a conversion is inexact, the value returned is rounded according to the rounding control
bits in the MXCSR register.
This instruction causes a transition from x87 FPU to MMX technology operation (that is, the x87 FPU top-of-stack
pointer is set to 0 and the x87 FPU tag word is set to all 0s [valid]). If this instruction is executed while an x87 FPU
floating-point exception is pending, the exception is handled before the CVTPI2PS instruction is executed.
In 64-bit mode, use of the REX.R prefix permits this instruction to access additional registers (XMM8-XMM15).

Operation

DEST[31:0] ← Convert_Integer_To_Single_Precision_Floating_Point(SRC[31:0]);

DEST[63:32] ← Convert_Integer_To_Single_Precision_Floating_Point(SRC[63:32]);

(* High quadword of destination unchanged *)

Intel C/C++ Compiler Intrinsic Equivalent

CVTPI2PS:

__m128 _mm_cvtpi32_ps(__m128 a, __m64 b)

SIMD Floating-Point Exceptions

Precision

Other Exceptions

See Table 22-5, “Exception Conditions for Legacy SIMD/MMX Instructions with XMM and FP Exception,” in the
Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 3B.

Opcode/

Instruction

Op/

En

64-Bit

Mode

Compat/

Leg Mode

Description

0F 2A /r
CVTPI2PS xmm, mm/m64

RM

Valid

Valid

Convert two signed doubleword integers

from mm/m64 to two single-precision

floating-point values in xmm.

Op/En

Operand 1

Operand 2

Operand 3

Operand 4

RM

ModRM:reg (w)

ModRM:r/m (r)

NA

NA
