CVTPI2PD—Convert Packed Dword Integers to Packed Double-Precision FP Values
INSTRUCTION SET REFERENCE, A-L
Vol. 2A 3-243
CVTPI2PD—Convert Packed Dword Integers to Packed Double-Precision FP Values
Instruction Operand Encoding
Description
Converts two packed signed doubleword integers in the source operand (second operand) to two packed double-
precision floating-point values in the destination operand (first operand).
The source operand can be an MMX technology register or a 64-bit memory location. The destination operand is an
XMM register. In addition, depending on the operand configuration:
•
For operands xmm, mm: the instruction causes a transition from x87 FPU to MMX technology operation (that
is, the x87 FPU top-of-stack pointer is set to 0 and the x87 FPU tag word is set to all 0s [valid]). If this
instruction is executed while an x87 FPU floating-point exception is pending, the exception is handled before
the CVTPI2PD instruction is executed.
•
For operands xmm, m64: the instruction does not cause a transition to MMX technology and does not take
x87 FPU exceptions.
In 64-bit mode, use of the REX.R prefix permits this instruction to access additional registers (XMM8-XMM15).
Operation
DEST[63:0] ← Convert_Integer_To_Double_Precision_Floating_Point(SRC[31:0]);
DEST[127:64] ← Convert_Integer_To_Double_Precision_Floating_Point(SRC[63:32]);
Intel C/C++ Compiler Intrinsic Equivalent
CVTPI2PD:
__m128d _mm_cvtpi32_pd(__m64 a)
SIMD Floating-Point Exceptions
None
Other Exceptions
Opcode/
Instruction
Op/
En
64-Bit
Mode
Compat/
Leg Mode
Description
66 0F 2A /r
CVTPI2PD xmm, mm/m64*
RM
Valid
Valid
Convert two packed signed doubleword
integers from mm/mem64 to two packed
double-precision floating-point values in xmm.
NOTES:
*Operation is different for different operand sets; see the Description section.
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM
ModRM:reg (w)
ModRM:r/m (r)
NA
NA
