CRC32 — Accumulate CRC32 Value
INSTRUCTION SET REFERENCE, A-L
3-224 Vol. 2A
CRC32 — Accumulate CRC32 Value
Instruction Operand Encoding
Description
Starting with an initial value in the first operand (destination operand), accumulates a CRC32 (polynomial
11EDC6F41H) value for the second operand (source operand) and stores the result in the destination operand. The
source operand can be a register or a memory location. The destination operand must be an r32 or r64 register. If
the destination is an r64 register, then the 32-bit result is stored in the least significant double word and
00000000H is stored in the most significant double word of the r64 register.
The initial value supplied in the destination operand is a double word integer stored in the r32 register or the least
significant double word of the r64 register. To incrementally accumulate a CRC32 value, software retains the result
of the previous CRC32 operation in the destination operand, then executes the CRC32 instruction again with new
input data in the source operand. Data contained in the source operand is processed in reflected bit order. This
means that the most significant bit of the source operand is treated as the least significant bit of the quotient, and
so on, for all the bits of the source operand. Likewise, the result of the CRC operation is stored in the destination
operand in reflected bit order. This means that the most significant bit of the resulting CRC (bit 31) is stored in the
least significant bit of the destination operand (bit 0), and so on, for all the bits of the CRC.
Operation
Notes:
BIT_REFLECT64: DST[63-0] = SRC[0-63]
BIT_REFLECT32: DST[31-0] = SRC[0-31]
BIT_REFLECT16: DST[15-0] = SRC[0-15]
BIT_REFLECT8: DST[7-0] = SRC[0-7]
MOD2: Remainder from Polynomial division modulus 2
Opcode/
Instruction
Op/
En
64-Bit
Mode
Compat/
Leg Mode
Description
F2 0F 38 F0 /r
CRC32 r32, r/m8
RM
Valid
Valid
Accumulate CRC32 on r/m8.
F2 REX 0F 38 F0 /r
CRC32 r32, r/m8*
RM
Valid
N.E.
Accumulate CRC32 on r/m8.
F2 0F 38 F1 /r
CRC32 r32, r/m16
RM
Valid
Valid
Accumulate CRC32 on r/m16.
F2 0F 38 F1 /r
CRC32 r32, r/m32
RM
Valid
Valid
Accumulate CRC32 on r/m32.
F2 REX.W 0F 38 F0 /r
CRC32 r64, r/m8
RM
Valid
N.E.
Accumulate CRC32 on r/m8.
F2 REX.W 0F 38 F1 /r
CRC32 r64, r/m64
RM
Valid
N.E.
Accumulate CRC32 on r/m64.
NOTES:
*In 64-bit mode, r/m8 can not be encoded to access the following byte registers if a REX prefix is used: AH, BH, CH, DH.
Op/En
Operand 1
Operand 2
Operand 3
Operand 4
RM
ModRM:reg (r, w)
ModRM:r/m (r)
NA
NA
