COMISD—Compare Scalar Ordered Double-Precision Floating-Point Values and Set EFLAGS

INSTRUCTION SET REFERENCE, A-L

Vol. 2A 3-185

COMISD—Compare Scalar Ordered Double-Precision Floating-Point Values and Set EFLAGS

Instruction Operand Encoding

Description

Compares the double-precision floating-point values in the low quadwords of operand 1 (first operand) and
operand 2 (second operand), and sets the ZF, PF, and CF flags in the EFLAGS register according to the result (unor-
dered, greater than, less than, or equal). The OF, SF and AF flags in the EFLAGS register are set to 0. The unor-
dered result is returned if either source operand is a NaN (QNaN or SNaN).
Operand 1 is an XMM register; operand 2 can be an XMM register or a 64 bit memory
location. The COMISD instruction differs from the UCOMISD instruction in that it signals a SIMD floating-point
invalid operation exception (#I) when a source operand is either a QNaN or SNaN. The UCOMISD instruction
signals an invalid numeric exception only if a source operand is an SNaN.
The EFLAGS register is not updated if an unmasked SIMD floating-point exception is generated.
VEX.vvvv and EVEX.vvvv are reserved and must be 1111b, otherwise instructions will #UD.
Software should ensure VCOMISD is encoded with VEX.L=0. Encoding VCOMISD with VEX.L=1 may encounter
unpredictable behavior across different processor generations.

Operation

COMISD (all versions)
RESULT OrderedCompare(DEST[63:0] <> SRC[63:0]) {
(* Set EFLAGS *) CASE (RESULT) OF

UNORDERED: ZF,PF,CF  111;
GREATER_THAN: ZF,PF,CF  000;
LESS_THAN: ZF,PF,CF  001;
EQUAL: ZF,PF,CF  100;

ESAC;
OF, AF, SF 0; }

Opcode/

Instruction

Op /

En

64/32

bit Mode

Support

CPUID

Feature

Flag

Description

66 0F 2F /r

COMISD xmm1, xmm2/m64

RM

V/V

SSE2

Compare low double-precision floating-point values in

xmm1 and xmm2/mem64 and set the EFLAGS flags

accordingly.

VEX.128.66.0F.WIG 2F /r

VCOMISD xmm1, xmm2/m64

RM

V/V

AVX

Compare low double-precision floating-point values in

xmm1 and xmm2/mem64 and set the EFLAGS flags

accordingly.

EVEX.LIG.66.0F.W1 2F /r

VCOMISD xmm1, xmm2/m64{sae}

T1S

V/V

AVX512F

Compare low double-precision floating-point values in

xmm1 and xmm2/mem64 and set the EFLAGS flags

accordingly.

Op/En

Operand 1

Operand 2

Operand 3

Operand 4

RM

ModRM:reg (w)

ModRM:r/m (r)

NA

NA

T1S

ModRM:reg (w)

ModRM:r/m (r)

NA

NA
