VERR/VERW—Verify a Segment for Reading or Writing

INSTRUCTION SET REFERENCE, V-Z

5-84 Vol. 2C

VERR/VERW—Verify a Segment for Reading or Writing

Instruction Operand Encoding

Description

Verifies whether the code or data segment specified with the source operand is readable (VERR) or writable (VERW)
from the current privilege level (CPL). The source operand is a 16-bit register or a memory location that contains
the segment selector for the segment to be verified. If the segment is accessible and readable (VERR) or writable
(VERW), the ZF flag is set; otherwise, the ZF flag is cleared. Code segments are never verified as writable. This
check cannot be performed on system segments.
To set the ZF flag, the following conditions must be met:

•

The segment selector is not NULL.

•

The selector must denote a descriptor within the bounds of the descriptor table (GDT or LDT).

•

The selector must denote the descriptor of a code or data segment (not that of a system segment or gate).

•

For the VERR instruction, the segment must be readable.

•

For the VERW instruction, the segment must be a writable data segment.

•

If the segment is not a conforming code segment, the segment’s DPL must be greater than or equal to (have
less or the same privilege as) both the CPL and the segment selector's RPL.

The validation performed is the same as is performed when a segment selector is loaded into the DS, ES, FS, or GS
register, and the indicated access (read or write) is performed. The segment selector's value cannot result in a
protection exception, enabling the software to anticipate possible segment access problems.
This instruction’s operation is the same in non-64-bit modes and 64-bit mode. The operand size is fixed at 16 bits.

Operation

IF SRC(Offset) > (GDTR(Limit) or (LDTR(Limit))

THEN ZF ← 0; FI;

Read segment descriptor;

IF SegmentDescriptor(DescriptorType)

0 (* System segment *)

or (SegmentDescriptor(Type)

≠

conforming code segment)

and (CPL > DPL) or (RPL > DPL)

THEN

ZF ← 0;

ELSE

IF ((Instruction

VERR) and (Segment readable))

or ((Instruction

VERW) and (Segment writable))

THEN

ZF ← 1;

FI;

Opcode

Instruction

Op/

64-Bit

Mode

Compat/

Leg Mode

Description

0F 00 /4

VERR r/m16

Valid

Set ZF=1 if segment specified with r/m16 can

be read.

0F 00 /5

VERW r/m16

Valid

Set ZF=1 if segment specified with r/m16 can

be written.

Op/En

Operand 1

Operand 2

Operand 3

Operand 4

ModRM:r/m (r)
