VCVTTPD2UQQ—Convert with Truncation Packed Double-Precision Floating-Point Values to Packed Unsigned Quadword Integers

INSTRUCTION SET REFERENCE, V-Z

5-54 Vol. 2C

VCVTTPD2UQQ—Convert with Truncation Packed Double-Precision Floating-Point Values to

Packed Unsigned Quadword Integers

Instruction Operand Encoding

Description

Converts with truncation packed double-precision floating-point values in the source operand (second operand) to
packed unsigned quadword integers in the destination operand (first operand).
When a conversion is inexact, the value returned is rounded according to the rounding control bits in the MXCSR
register. If a converted result cannot be represented in the destination format, the floating-point invalid exception
is raised, and if this exception is masked, the integer value 2

w

 – 1 is returned, where w represents the number of

bits in the destination format.
EVEX encoded versions: The source operand is a ZMM/YMM/XMM register or a 512/256/128-bit memory location.
The destination operation is a ZMM/YMM/XMM register conditionally updated with writemask k1.
Note: EVEX.vvvv is reserved and must be 1111b, otherwise instructions will #UD.

Operation

VCVTTPD2UQQ (EVEX encoded versions) when src operand is a register
(KL, VL) = (2, 128), (4, 256), (8, 512)
FOR j  0 TO KL-1

i  j * 64
IF k1[j] OR *no writemask*

THEN DEST[i+63:i] 

Convert_Double_Precision_Floating_Point_To_UQuadInteger_Truncate(SRC[i+63:i])

ELSE

IF *merging-masking*

; merging-masking

THEN *DEST[i+63:i] remains unchanged*
ELSE ;

zeroing-masking

DEST[i+63:i]  0

FI

FI;

ENDFOR
DEST[MAX_VL-1:VL]  0

Opcode/

Instruction

Op /

En

64/32

bit Mode

Support

CPUID

Feature

Flag

Description

EVEX.128.66.0F.W1 78 /r

FV

V/V

AVX512VL

Convert two packed double-precision floating-point values

from xmm2/m128/m64bcst to two packed unsigned

quadword integers in xmm1 using truncation with

writemask k1.

VCVTTPD2UQQ xmm1 {k1}{z},

xmm2/m128/m64bcst

AVX512DQ

EVEX.256.66.0F.W1 78 /r

FV

V/V

AVX512VL

Convert four packed double-precision floating-point values

from ymm2/m256/m64bcst to four packed unsigned

quadword integers in ymm1 using truncation with

writemask k1.

VCVTTPD2UQQ ymm1 {k1}{z},

ymm2/m256/m64bcst

AVX512DQ

EVEX.512.66.0F.W1 78 /r

FV

V/V

AVX512DQ

Convert eight packed double-precision floating-point values

from zmm2/mem to eight packed unsigned quadword

integers in zmm1 using truncation with writemask k1.

VCVTTPD2UQQ zmm1 {k1}{z},

zmm2/m512/m64bcst{sae}

Op/En

Operand 1

Operand 2

Operand 3

Operand 4

FV

ModRM:reg (w)

ModRM:r/m (r)

NA

NA
