STOS/STOSB/STOSW/STOSD/STOSQ—Store String

INSTRUCTION SET REFERENCE, M-U

4-648 Vol. 2B

STOS/STOSB/STOSW/STOSD/STOSQ—Store String

Instruction Operand Encoding

Description

In non-64-bit and default 64-bit mode; stores a byte, word, or doubleword from the AL, AX, or EAX register
(respectively) into the destination operand. The destination operand is a memory location, the address of which is
read from either the ES:EDI or ES:DI register (depending on the address-size attribute of the instruction and the
mode of operation). The ES segment cannot be overridden with a segment override prefix.
At the assembly-code level, two forms of the instruction are allowed: the “explicit-operands” form and the “no-
operands” form. The explicit-operands form (specified with the STOS mnemonic) allows the destination operand to
be specified explicitly. Here, the destination operand should be a symbol that indicates the size and location of the
destination value. The source operand is then automatically selected to match the size of the destination operand
(the AL register for byte operands, AX for word operands, EAX for doubleword operands). The explicit-operands
form is provided to allow documentation; however, note that the documentation provided by this form can be
misleading. That is, the destination operand symbol must specify the correct type (size) of the operand (byte,
word, or doubleword), but it does not have to specify the correct location. The location is always specified by the
ES:(E)DI register. These must be loaded correctly before the store string instruction is executed.
The no-operands form provides “short forms” of the byte, word, doubleword, and quadword versions of the STOS
instructions. Here also ES:(E)DI is assumed to be the destination operand and AL, AX, or EAX is assumed to be the
source operand. The size of the destination and source operands is selected by the mnemonic: STOSB (byte read
from register AL), STOSW (word from AX), STOSD (doubleword from EAX).
After the byte, word, or doubleword is transferred from the register to the memory location, the (E)DI register is
incremented or decremented according to the setting of the DF flag in the EFLAGS register. If the DF flag is 0, the
register is incremented; if the DF flag is 1, the register is decremented (the register is incremented or decremented
by 1 for byte operations, by 2 for word operations, by 4 for doubleword operations).

Opcode

Instruction

Op/

64-Bit

Mode

Compat/

Leg Mode

Description

STOS m8

Valid

For legacy mode, store AL at address ES:(E)DI;

For 64-bit mode store AL at address RDI or

EDI.

STOS m16

Valid

For legacy mode, store AX at address ES:(E)DI;

For 64-bit mode store AX at address RDI or

EDI.

STOS m32

Valid

For legacy mode, store EAX at address

ES:(E)DI; For 64-bit mode store EAX at address

RDI or EDI.

REX.W + AB

STOS m64

Valid

N.E.

Store RAX at address RDI or EDI.

STOSB

Valid

For legacy mode, store AL at address ES:(E)DI;

For 64-bit mode store AL at address RDI or

EDI.

STOSW

Valid

For legacy mode, store AX at address ES:(E)DI;

For 64-bit mode store AX at address RDI or

EDI.

STOSD

Valid

For legacy mode, store EAX at address

ES:(E)DI; For 64-bit mode store EAX at address

RDI or EDI.

REX.W + AB

STOSQ

Valid

N.E.

Store RAX at address RDI or EDI.

Op/En

Operand 1

Operand 2

Operand 3

Operand 4
