SARX/SHLX/SHRX — Shift Without Affecting Flags

INSTRUCTION SET REFERENCE, M-U

Vol. 2B 4-587

SARX/SHLX/SHRX — Shift Without Affecting Flags

Instruction Operand Encoding

Description

Shifts the bits of the first source operand (the second operand) to the left or right by a COUNT value specified in
the second source operand (the third operand). The result is written to the destination operand (the first operand).
The shift arithmetic right (SARX) and shift logical right (SHRX) instructions shift the bits of the destination operand
to the right (toward less significant bit locations), SARX keeps and propagates the most significant bit (sign bit)
while shifting.
The logical shift left (SHLX) shifts the bits of the destination operand to the left (toward more significant bit loca-
tions).
This instruction is not supported in real mode and virtual-8086 mode. The operand size is always 32 bits if not in
64-bit mode. In 64-bit mode operand size 64 requires VEX.W1. VEX.W1 is ignored in non-64-bit modes. An
attempt to execute this instruction with VEX.L not equal to 0 will cause #UD.
If the value specified in the first source operand exceeds OperandSize -1, the COUNT value is masked.
SARX,SHRX, and SHLX instructions do not update flags.

Operation

TEMP ← SRC1;

IF VEX.W1 and CS.L = 1
THEN

countMASK ←3FH;

Opcode/

Instruction

Op/

En

64/32

-bit

Mode

CPUID

Feature

Flag

Description

VEX.NDS

1

.LZ.F3.0F38.W0 F7 /r

NOTES:

1. ModRM:r/m is used to encode the first source operand (second operand) and VEX.vvvv encodes the second source operand (third oper-

and).

RMV

V/V

BMI2

Shift r/m32 arithmetically right with count specified in r32b.

SARX r32a, r/m32, r32b

VEX.NDS

1

.LZ.66.0F38.W0 F7 /r

RMV

V/V

BMI2

Shift r/m32 logically left with count specified in r32b.

SHLX r32a, r/m32, r32b

VEX.NDS

1

.LZ.F2.0F38.W0 F7 /r

RMV

V/V

BMI2

Shift r/m32 logically right with count specified in r32b.

SHRX r32a, r/m32, r32b

VEX.NDS

1

.LZ.F3.0F38.W1 F7 /r

RMV

V/N.E.

BMI2

Shift r/m64 arithmetically right with count specified in r64b.

SARX r64a, r/m64, r64b

VEX.NDS

1

.LZ.66.0F38.W1 F7 /r

RMV

V/N.E.

BMI2

Shift r/m64 logically left with count specified in r64b.

SHLX r64a, r/m64, r64b

VEX.NDS

1

.LZ.F2.0F38.W1 F7 /r

RMV

V/N.E.

BMI2

Shift r/m64 logically right with count specified in r64b.

SHRX r64a, r/m64, r64b

Op/En

Operand 1

Operand 2

Operand 3

Operand 4

RMV

ModRM:reg (w)

ModRM:r/m (r)

VEX.vvvv (r)

NA
