POP—Pop a Value from the Stack

INSTRUCTION SET REFERENCE, M-U

4-386 Vol. 2B

The address size is used only when writing to a destination operand in memory.

•

Operand size. The D flag in the current code-segment descriptor determines the default operand size; it may
be overridden by instruction prefixes (66H or REX.W).
The operand size (16, 32, or 64 bits) determines the amount by which the stack pointer is incremented (2, 4
or 8).

•

Stack-address size. Outside of 64-bit mode, the B flag in the current stack-segment descriptor determines the
size of the stack pointer (16 or 32 bits); in 64-bit mode, the size of the stack pointer is always 64 bits.
The stack-address size determines the width of the stack pointer when reading from the stack in memory and
when incrementing the stack pointer. (As stated above, the amount by which the stack pointer is incremented
is determined by the operand size.)

If the destination operand is one of the segment registers DS, ES, FS, GS, or SS, the value loaded into the register
must be a valid segment selector. In protected mode, popping a segment selector into a segment register automat-
ically causes the descriptor information associated with that segment selector to be loaded into the hidden
(shadow) part of the segment register and causes the selector and the descriptor information to be validated (see
the “Operation” section below).
A NULL value (0000-0003) may be popped into the DS, ES, FS, or GS register without causing a general protection
fault. However, any subsequent attempt to reference a segment whose corresponding segment register is loaded
with a NULL value causes a general protection exception (#GP). In this situation, no memory reference occurs and
the saved value of the segment register is NULL.
The POP instruction cannot pop a value into the CS register. To load the CS register from the stack, use the RET
instruction.
If the ESP register is used as a base register for addressing a destination operand in memory, the POP instruction
computes the effective address of the operand after it increments the ESP register. For the case of a 16-bit stack
where ESP wraps to 0H as a result of the POP instruction, the resulting location of the memory write is processor-
family-specific.
The POP ESP instruction increments the stack pointer (ESP) before data at the old top of stack is written into the
destination.
A POP SS instruction inhibits all interrupts, including the NMI interrupt, until after execution of the next instruction.
This action allows sequential execution of POP SS and MOV ESP, EBP instructions without the danger of having an
invalid stack during an interrupt

1

. However, use of the LSS instruction is the preferred method of loading the SS

and ESP registers.
In 64-bit mode, using a REX prefix in the form of REX.R permits access to additional registers (R8-R15). When in
64-bit mode, POPs using 32-bit operands are not encodable and POPs to DS, ES, SS are not valid. See the summary
chart at the beginning of this section for encoding data and limits.

Operation

IF StackAddrSize

=

 32

THEN

IF OperandSize

=

32

THEN

DEST ← SS:ESP; (* Copy a doubleword *)

ESP ← ESP + 4;

ELSE (* OperandSize

=

 16*)

DEST ← SS:ESP; (* Copy a word *)

1. If a code instruction breakpoint (for debug) is placed on an instruction located immediately after a POP SS instruction, the breakpoint

may not be triggered. However, in a sequence of instructions that POP the SS register, only the first instruction in the sequence is

guaranteed to delay an interrupt.
In the following sequence, interrupts may be recognized before POP ESP executes:
POP SS

POP SS

POP ESP
